Audio
Frequency range:The lowest and the hightest frequencies that can be inputted/produced.
50 - 60 Hz
Audio formats supported:The audio formats which this device or software can read/use e.g. MP3, MP4.
RTSP
Audio output channels:An audio output channel is an electric circuit which acts as a path for a signal produced by a device. A device may have several audio output channels.
2 channels
Audio input channels:A channel is an electric circuit which acts as a path for a signal. Audio input channels allow audio signals to be communicated to the device.
2 channels
Audio system full duplex:
Audio system:System used to play music or speech.
2-way
Built-in speaker(s):The device contains speaker(s) to produce sound.
Camera
Camera shutter speed:Determines the length of time the shutter lets light pass through the lens to the CCD. Shutter speed and aperture together determine exposure.
1/19500 - 1 s
Lens viewing angle, vertical:
71.5 - 30.0°
Lens viewing angle, horizontal:
360°
Horizontal field of view (thermal module):
360°
Minimum illumination:Also known as light sensitivity, this is the smallest amount of light needed for the camera to produce an image of useable quality.
0.1 lx
Design
International Protection (IP) code:The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
IP66
Housing material:
Aluminium, Polycarbonate (PC)
Product colour:
Black, White
Mounting type:Type of mounting e.g. wall mounting.
Ceiling/wall
Form factor:The shape or design of the product.
Dome
Features
License plate recognition:
Image sensor
Progressive scan:Also referred to as noninterlaced scanning, this is a way of displaying, storing, or transmitting moving images in which all the lines of each frame are drawn in sequence. This is in contrast to interlaced video used in traditional analog television systems where only the odd lines, then the even lines of each frame (each image called a video field) are drawn alternately.Progressive scan is used for DVDs and HDTV (high defintion television).
Optical sensor size:Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
25.4 / 2.78 mm (1 / 2.78")
Sensor type:A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
CMOS
Lens system
Focal length range:
3.18 - 7.42 mm
Zoom capability:The amount that the camera lens can zoom.
Management features
Remotely operated:The device can be controlled by remote control, which is a device that controls an apparatus by means of radio or infrared signals.
Network
Number of simultaneous live view channels:
4 channels
Quality of Service (QoS) support:
Streaming method:
Multicast
Supported network protocols:Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet interface type:
Fast Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Networking
Number of simultaneous live view channels:
4 channels
Quality of Service (QoS) support:
Streaming method:
Multicast
Supported network protocols:Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Networking standards:The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet interface type:
Fast Ethernet
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Night vision
Infra-red wavelength:
850 nm
Number of illumination LEDs:
2
Night vision distance:
20 m
Night vision:Night vision is technology which allows you to see in low light conditions.
Operational conditions
Storage relative humidity (H-H):
5 - 95%
Operating relative humidity (H-H):
10 - 100%
Storage temperature (T-T):The minimum and maximum temperatures at which the product can be safely stored.
-40 - 65 °C
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
-40 - 50 °C
Other features
Doesn't contain:
BFR, CFR, PVC
Warranty period:
5 year(s)
Packaging content
Mounting brackets included:
Number of cameras:The quantity of cameras that product can support.
1
Panoramic camera
Signal-to-Noise Ratio (SNR) (panoramic camera):
55 dB
Sensor type (panoramic camera):
CMOS
Performance
Languages support:The product has support (help) for languages.
Arabic, Simplified Chinese, Traditional Chinese, Czech, Dutch, English, Finnish, French, Greek, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Built-in light:There is a light which is inside/on the outside of the product.
Infrared (IR) cut-off filter:
Wide Dynamic Range (WDR):
Maximum operating distance:The maximum distance from which you can operate the device.
20 m
Connectivity technology:
Wired
Placement supported:Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
Outdoor
Type:Characteristics of the device.
IP security camera
Ports & interfaces
Ethernet LAN (RJ-45) ports:Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
Power
Power consumption (max):The maximum amount of power used by the device.
23.7 W
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
10.8 W
Power source type:What the power source is.
PoE
Security
Alert notification type:
E-mail
Human and vehicle targets classification:
Intelligent Video Surveillance (IVS) system features:
Human detection, Vehicle detection
Motion sensor:Device that detects moving objects, particularly people. A motion detector is often integrated as a component of a system that automatically performs a task or alerts a user of motion in an area. Motion detectors form a vital component of security, automated lighting control, home control, energy efficiency, and other useful systems.
Network access storage (NAS):
Security algorithms:Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
256-bit AES-XTS, FIPS 140-2, HTTPS, SNMP
Password protection:The computer, smartphone etc. can only be used when the correct password is entered, therefore making it more secure.
Storage
Compatible memory cards:Types of memory cards which can be used with this product.
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Sustainability
Compliance certificates:
BSMI, CE, Federal Communications Commission (FCC), ICES, KC, RCM, REACH, RoHS, Trade Agreements Act (TAA), UL, VCCI, cUL
Video
Bit rate control:
Variable Bit Rate (VBR)
Image quality adjustment:
Brightness, Contrast, Mirror, Saturation, Sharpness
Image stabilizer:This camera function compensates for slight shaking movements caused by an unstable position and ensures smooth footage even in suboptimal conditions.
Noise reduction technology:
2D noise reduction, 3D noise reduction
Video intelligence analytic:
Video recording:Recording moving visual images.
Supported graphics resolutions:The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
640 x 360, 640 x 480 (VGA), 2560 x 1440, 2592 x 1944
Video compression formats:
M-JPEG, MPEG, MPEG4
Video formats supported:The type of video formats that can be used by this device.
H.264, H.265
Total megapixels:A megapixel (MP or Mpx) is one million pixels, and is a term used not only for the number of pixels in an image, but also to express the number of image sensor elements of digital cameras or the number of display elements of digital displays. For example, a camera that makes a 2048 × 1536 pixel image typically uses a few extra rows and columns of sensor elements and is commonly said to have "3.2 megapixels" or "3.4 megapixels", depending on whether the number reported is the "effective" or the "total" pixel count (as opposed to the 2048 × 1536 = 3,145,728 finished image pixels).
5 MP
Maximum resolution:The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
2592 x 1944 pixels
Weight & dimensions
Weight:Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
3 kg
Height:The measurement of the product from head to foot or from base to top.
75 mm
Depth:The distance from the front to the back of something.
220 mm
Width:The measurement or extent of something from side to side.
141 mm
