Design
Market positioning:
Graphics design
Display
sRGB coverage (typical):
100%
Colour gamut standard:
sRGB
Viewable size, vertical:
33.6 cm
Viewable size, horizontal:The viewable size is often somewhat smaller than the actual size of a monitor, because there is a border around the image.
59.7 cm
Vertical scan range:
50 - 76 Hz
Horizontal scan range:
30 - 89 kHz
Pixel pitch:This is the parameter of a picture tube, which specifies the shortest distance between two dots of the same colour. The principle is: the smaller the dot pitch, the better sharpness of image.
0.2331 x 0.2331 mm
Display number of colours:
1.073 billion colours
Viewing angle, vertical:Maximum vertical angle at which a display can be viewed with acceptable visual performance.
178°
Viewing angle, horizontal:Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
178°
Maximum refresh rate:
60 Hz
Contrast ratio (typical):The difference in light intensity between the brightest white and the darkest black.
1000:1
Anti-glare screen:Always gives an optimal view, even in direct sunlight.
Response time:The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)
4 ms
Display brightness (typical):
350 cd/m²
HD type:Type of supported High Definition (e.g. Full HD, 4K Ultra HD).
Quad HD
Touchscreen:A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
Display technology:The technology used in the display e.g. plasma, LED.
LED
Native aspect ratio:The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
16:9
Display resolution:The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
2560 x 1440 pixels
Display diagonal:Size of the display for this product, measured diagonally, usually in inches.
68.6 cm (27")
Ergonomics
Number of OSD languages:
18
On Screen Display (OSD) languages:
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Hungarian, Italian, Polish, Portuguese, Romanian, Russian, Swedish
Tilt angle range:
-5 - 20°
Tilt adjustment:The tilt, which means the angle at which the device is pointing (up or down), can be changed.
Swivel angle range:
-45 - 45°
Adjustable height (max):
13 cm
Height adjustment:The part of the device that can be adjusted to change the height.
Cable lock slot type:
Kensington
Cable lock slot:Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc.
Panel mounting interface:
100 x 100 mm
Logistics data
Harmonized System (HS) code:
85285210
Multimedia
Built-in camera:The product has an integrated camera.
RMS rated power:RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplfiers and loudspeakers.
2 W
Number of speakers:The quantity of speakers included in/with the product.
2
Built-in speaker(s):The device contains speaker(s) to produce sound.
Network
Ethernet LAN:An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Operational conditions
Storage relative humidity (H-H):
10 - 90%
Operating relative humidity (H-H):
20 - 90%
Storage temperature (T-T):The minimum and maximum temperatures at which the product can be safely stored.
-20 - 60 °C
Operating temperature (T-T):The minimum and maximum temperatures at which the product can be safely operated.
5 - 40 °C
Other features
Monitor maximum video bandwidth:
270 MHz
Certification:
TUV GS, CE, ISO9241-307, CO? 6.0
Mean time between failures (MTBF):Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
60000 h
Placement supported:Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
Horizontal/Vertical
TV tuner integrated:Device has an in-built TV tuner.
On/off switch:The button which is pressed to switch the device on or off.
Display:The description of display that can includes display type, resolution, size etc.
LED
Country of origin:Country where the device is made.
China
Packaging content
Bundled software:Software distributed with another product such as a piece of computer hardware or other electronic device, or a group of software packages which are sold together. A software suite is an example of bundled software, as is software which is pre-installed on a new computer.
Display Pilot?
Quick start guide:Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.
Cables included:
AC, DisplayPort, HDMI, USB
Packaging data
Performance
Low Blue Light technology:
Ports & interfaces
HDCP:High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
Headphone outputs:Number of sockets /ports where headphones are connected.
1
Mini DisplayPorts quantity:
1
DisplayPorts quantity:Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
1
HDMI ports quantity:The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
1
HDMI:HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
DVI port:Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.
VGA (D-Sub) ports quantity:Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.
0
USB Type-A downstream ports quantity:
2
Number of upstream ports:
1
Power
European Product Registry for Energy Labelling (EPREL) code:
342294
Energy efficiency scale:
A to G
AC input voltage:The voltage of the AC electricity that is inpitted into the product.
90 - 264 V
Power consumption (off):
0.3 W
Power consumption (standby):The amount of electricity that is consumed when the product is on standby.
0.4 W
Power consumption (typical):Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
32 W
Energy consumption (SDR) per 1000 hours:
32 kWh
Energy efficiency class (SDR):
G
Thin Client
Thin client installed:The product includes a thin client, which is a computer or a computer program which depends heavily on some other computer (its server) to fulfill its computational roles. This is different from the traditional fat client, which is a computer designed to take on these roles by itself. The specific roles assumed by the server may vary, from providing data persistence (for example, for diskless nodes) to actual information processing on the client's behalf.
Weight & dimensions
Weight (without stand):
6.9 kg
Height (without stand):
379.5 mm
Depth (without stand):
56.5 mm
Width (without stand):
641 mm
Weight (with stand):
9.1 kg
Height (with stand):
547.3 mm
Depth (with stand):
239.7 mm
Width (with stand):
641 mm
